Features
- Thermal broken performance
- EPDM seal gaskets on exterior and interior
- Setting for double glazing
- Multiple sight line and middle rail options
- Welded corner joint
- Compatible with curtain wall and storefront systems
Frames
- System depth: 57.2mm (2 1/4″)
- Wall thickness: 3.2mm (1/4″)
- Thermal break depth: 16.0mm (5/8″) polyamide
- Stile sightline options: 63.5mm (2 1/2″), 101.6mm (4″)
- Top rail sightline options: 98.4mm (3 7/8″)
- Middle rail sightline options: 98.4mm (3 7/8″), 152.4mm (6″)
- Bottom rail sightline options: 98.4mm (3 7/8″), 152.4mm (6″)
Glass
- Double Glazed: 22mm (7/8″)
3570 Thermal Door Data
For CAD details, test reports, fabrication manual, and glazing manual, please contact your sales representatives.
